EL2622 | 2-channel relay output terminal 230 V AC, 5 A, potential-free make contacts, no power contacts
Digital output EL2622 Beckhoff Vietnam
EtherCAT Terminal EL2622 Beckhoff Vietnam
Technical data |
EL2622 | ES2622 |
Connection technology |
relay output |
Number of outputs |
2 x make contacts |
Nominal voltage |
230 V AC/30 V DC |
Load type |
ohmic, inductive, lamp load |
Distributed clocks |
– |
Ohmic switching current |
5 A AC/DC per channel |
Inductive switching current |
2 A AC/DC per channel |
Minimum permitted load |
10 mA at 5 V DC |
Lamp test, electronic ballast |
4 x 58 W |
Current consumption E-bus |
typ. 170 mA |
Electrical isolation |
500 V (E-bus/field potential) |
Current consumption power contacts |
– |
Bit width in the process image |
2 outputs |
Operating cycles mech. (min.) |
2 x 107 |
Operating cycles electr. (min.) |
1 x 105 (5 A/30 V DC) |
Configuration |
no address or configuration setting |
Special features |
– |
Weight |
approx. 50 g |
Operating/storage temperature |
0…+55 °C/-25…+85 °C |
Relative humidity |
95 %, no condensation |
Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
Protect. class/installation pos. |
IP 20/variable |
Pluggable wiring |
for all ESxxxx terminals |
Approvals |
CE, UL |
| Nhà cung cấp | Đại lý Beckhoff |
|---|---|
| Xuất xứ | Đức |
