Type

MC-4/01

MC-4/03

MC-4/05

Rated current

1,5 Aeff

3 Aeff

5 Aeff

Peak current

3,75 Aeff

7,5 Aeff

12.5 Aeff

Rated power

1,1 kVA

2,1 kVA

1.9 kVA

Width

69 mm

69 mm

69 mm

Type

MC-4/10

MC-4/22

MC-4/50

Rated current

10 Aeff

22 Aeff

50 Aeff

Peak current

25 Aeff

55 Aeff

125 Aeff

Rated power

6.9 kVA

15,2 kVA

34,5 kVA

Width

69 mm

124 mm

312 mm

Supply voltage

3 AC 342 … 528 V/ MC-4/05: 1 AC 230 V

Supply frequency

48 … 62 Hz

Control voltage

DC 20 … 30 V

Bleeder resistance

integrated

Peak torque

5,2 Nm

Power supply and power filter

integrated

Safety funtions*

Safe Stop 1 (SS1)** and Safe Torque Off (STO)** via Inverter Enable

Motion bus

sercos interface

 Depth

230 / 260 mm with connector plugs

Height

240 / 310 mm with fixtures

Protection class

IP 20

Ambient temperature

+5° C … + 45° C; (…+55° C)

Excess voltage category

KIII, T2 (DIN VDE 0110)

Excess voltage resistance

class 1 (DIN VDE 0160)

Degree of radio interference

class A EN 55011 / EN 61800-3

Certifications

CE / UL 7 cUL
