Accuracy:

±0.1% of full scale

Sampling rate:

14,000 Hz

Power:

AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low.

Battery Life:

Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use

Measurement units:

lbF, ozF, gF, kgF, N, kN, mN (depending on model)

Outputs:

USB / RS-232: Configurable up to 115,200 baud. Automatic output available up to 250 Hz. Includes Gauge Control Language 2 for full computer control.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VDC, ±0.25% of full scale at capacity,
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines.

Safe overload:

200% of full scale (display shows “OVER” at 110% and above)

Weight:

M7-012 – M7-100: 1.0 lb [0.45 kg]
M7-200 – M7-500: 1.2 lb [0.54 kg]

Included items:

Carrying case with chisel, cone, V-groove, hook, flat, extension rod, universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESUR™ Lite software, MESUR™gauge and MESUR™gauge Plus 90-day trial, and user’s guide), and NIST-traceable certificate of calibration with data.

Environmental requirements:

40 – 100°F, max. 96% humidity, non-condensating

Warranty:

3 years (see individual statement for further details)

Model

lbF

ozF

kgF

gF

N

kN

mN

M7-012

0.12 x 0.00002

2 x 0.0005

–

50 x 0.01

0.5 x 0.0001

–

500 x 0.1

M7-025

0.25 x 0.00005

4 x 0.001

–

100 x 0.02

1 x 0.0002

–

1000 x 0.2

M7-05

0.5 x 0.0001

8 x 0.002

–

250 x 0.05

2.5 x 0.0005

–

2500 x 0.5

M7-2

2 x 0.0005

32 x 0.01

1 x 0.0002

1000 x 0.2

10 x 0.002

–

–

M7-5

5 x 0.001

80 x 0.02

2.5 x 0.0005

2500 x 0.5

25 x 0.005

–

–

M7-10

10 x 0.002

160 x 0.05

5 x 0.001

5000 x 1

50 x 0.01

–

–

M7-20

20 x 0.005

320 x 0.1

10 x 0.002

10000 x 2

100 x 0.02

–

–

M7-50

50 x 0.01

800 x 0.2

25 x 0.005

25000 x 5

250 x 0.05

–

–

M7-100

100 x 0.02

1600 x 0.5

50 x 0.01

50000 x 10

500 x 0.1

–

–

M7-200

200 x 0.05

3200 x 1

100 x 0.02

–

1000 x 0.2

1 x 0.0002

–

M7-500

500 x 0.1

8000 x 2

250 x 0.05

–

2500 x 0.5

2.5 x 0.0005

–
