ibaPDA-Interface-Modbus-TCP-Client

Product number: 31.001022

ibaPDA Interface: Modbus TCP/IP Client

PDA Modbus TCP/IP Interface for communication with systems and devices which supports Modbus Server functionality.

Technical Data:

• PDA driver decoding for Modbus over TCP/IP
• Client functionality:
  – Active communication partner
  – Initiates the Modbus communication
  – Requests data from a Modbus server
• Useable for Devices with Modbus TCP/IP Server functionality and Modbus serial devices behind a Modbus TCP/IP to serial Gateway
• The following Modbus register can be read (supported Modbus Function codes):
  – Coils (Modbus Function code 1)
  – Discrete Inputs (Modbus Function code 2)
  – Holding registers (Modbus Function code 3)
  – Input registers (Modbus Function code 4)
• The type of function codes to choose depends on the Modbus server.
• Number of connections/modules: 64

Special Remarks:

• Requires a PDA basic license
• Please provide to us the dongle number of the existing PDA license with your order that we can prepare the license extension for your dongle
• If there are more than 64 communication connections (modules) required, the interface can be extended with additional 64 interfaces (modules) with the license “one-step-up- Interface-Modbus over TCPIP – Client”. This license extension can be used 3 times per interface and allows in total 256 connections (modules) per interface.

Weight: 0,10 kg
