Features

• Wide range of flow ratings

• Operating temperature range 33 to 125°F (1°C to 52°C)

• Pressure ratings up to 500 psig / 34 bar

• Two accuracy levels to choose from: 2% or 1% Full Scale

• Optional high and low-flow reed switch or inductive alarm, also for safe use in explosive hazardous areas

• Calibrated to process conditions with 127mm or high resolution 250mm direct reading scales

• Brass or 316L stainless steel end fittings

• Flanged or threaded connections

• Horizontal or vertical connections

• Horizontal end fittings 360° rotatable

• 180° viewing window

• Rugged, vented polycarbonate enclosure available on most models

Benefits

• Tube and float can be re-ranged in line, minimizing process downtime

• Rotatable connections for easy installation at any angle

• Packing gland or O-ring sealing to meet piping requirements or customer preference

• No power required; reduces installation cost and provides flow measurement in hazardous areas

• Low-pressure drop allows for economical pump selection

• Optional needle valve mounted to inlet or outlet for setting the desired flow

• Optional economical brass fittings for delicate applications (e.g. avoidance of hydrogen embrittlement)

Applications

• Industrial processes

• Pharmaceutical production

• Oil and gas pumping and refining processes

• Chemical manufacturing

• Burner control

• Water treatment and distribution systems
