Contacted type Level Transmitter ALT6100 Autrol

Drawings ALT 6100 OUTLINE:

Function Level Transmitter ALT 6100:

Type	Contacted type Level Transmitter
Certificate	Ex d, KCs, CE, Rohs, IP66/67
Feature	Rod, Coxial, Cable
Range	0.15 to 20m
Technology	Time Domain Refletometry(TDR) by Guided Wave Radar
Applicable condition	Low Viscosity, Less Emulsion or Foam
Point Feature	Liquid Application

Specification Level Transmitter ALT 6100:

Model Name	ALT6100
Protocol	Digital Communication, HART 7
Trim ability	Zero, DAC, FULL
Power supply & Load Requirement	250 to 360 ohm @ 24 Vdc, Loop Powered
Falure Mode	Low ≤ 3.78 mA, High ≥ 21.1 mA
External Buttons	Zero & Span 2 buttons for device configuration
Process Temp. limit	-40 to 80℃ ( -104 to 176℉ )
Accuracy	± 3mm or ± 0.03% of SC whichever is greater
