Đại lý ROMER FORDERTECHNIK tại Việt Nam

Phanh đĩa type RST ROMER FORDERTECHNIK

DISC BRAKE TYPE RST / SERVICE BRAKE

Product description

“Fast speed” brake. Fail-Safe principle!

• Torque adjustable
• For brake disc ø 250 mm to ø 1250 mm
• Braking torques from 200 Nm up to 22000 Nm per brake
• NEW OPTION: With “SLM” synchro-lifting-mechanism (guarantees equal air gaps between brake lining and brake disc)
• MADE IN GERMANY, own production

FUNCTIONAL PRINCIPLE

• Braking by spring force
• Lifting electro-hydraulically (thruster) – Standard version
• Different sizes:
• RST-0, RST-0-L (horizontal), RST-1, RST-2, RST-3, RST-4
• Vertical and horizontal versions (RST-0-L)
• Sintered brake linings as standard for higher friction speeds

OPTIONS

• Limit switch protection: Mechanical or inductive
• “Brake opened”, “Brake closed”, “Brake check/wear”
• Hand lifting device
• Safety limit switch for “hand lifting device in use”
• Automatic wear adjustment (AVN)
• Special painting (Please specify RAL color)
• Special construction
• Thruster TURBO Control System (faster brake reaction times)
• Cooling systems for thrusters / Protection against overheating
